Agilent二手N4433A价格

Agilent 安捷伦 N4433A四端口|网络分析仪校准件|20GHz|3.5mm

Agilent 安捷伦 N4433A四端口|网络分析仪校准件|20GHz|3.5mm

N4433A-010 Fo

--------------------------------------------------------------------黄S：15015266767（同微）；

Q号：2441688423；

地址：广东省东莞市塘厦镇美华中心703

公司：东莞市亿测电子有限公司

------------------------------------------------------------------------------------------

重要提示：如果您找不到手机号，请看图片，或者百度搜索“亚宸电子”

ur 3.5 mm female connectors
N4433A-101 Port A connector is 3.5 mm female
N4433A-102 Port A connector is 3.5 mm male
N4433A-150 Wooden storage box
N4433A-1A7 Calibration + Uncertainties + Guardbanding
N4433A-201 Port B connector is 3.5 mm female
N4433A-202 Port B connector is 3.5 mm male
N4433A-301 Port C connector is 3.5 mm female
N4433A-302 Port C connector is 3.5 mm male
N4433A-401 Port D connector is 3.5 mm female
N4433A-402 Port D connector is 3.5 mm male
N4433A-A6J ANSI Z540-1-1994 Calibration
N4433A-ABA Printed manual English
N4433A-ATP02 ATP Lead time for Option H43
N4433A-UK6 Commercial calibration certificate with test data
买卖二手N4433A-回收N4433A
 主要特性与技术指标

    频率范围从300 kHz至20 GHz
    标准的3.5 mm阴性连接器
    通过单一连接进行快速完整的3端口或4端口校准
    NIST标准精确校准
    减小连接器磨损
    通过USB接口直接控制PNA和ENA系列网络分析仪
    可靠的固态开关
    混合的3.5 mm阳性/阴性连接器选

主要技术指标
* 300 kHz to 20 GHz frequency range
* Standard 3.5 mm (f) connectors
* Fast full 3- or 4-port calibration with a single connection
* NIST traceable accurate calibrations
* Reduced connector wear
* USB interface for direct control with PNA and ENA series of network analyzers
* Reliable solid-state switching
* Mixed 3.5 mm male/female connectors option a
